About This Plan
The Narrow Lot Cottage House Plan is a single-storey Cabin house plan offering 154m² of living space with 5 bedrooms and 3 bathrooms. This design features covered parking and is built on a standard foundation, making it well suited for a range of South African building sites. Priced at R27 207,36 in South African Rand, this plan is available for immediate digital delivery. Choose from PDF (single or multi-build licence) or CAD files for your architect or engineer to modify. All plans from BH Designs include full construction drawings — floor plans, elevations, cross-sections, electrical and plumbing layouts. Your local professional can review and stamp the drawings for municipal submission under SANS 10400. With generous living space, this home is ideal for growing families who need room to spread out.
The great room in this narrow lot cottage house plan redefines the terms; open floor plan, versatile and spaciousness with its 23'-foot clear span width and partial vaulted ceiling
The two second floor bedrooms with ten and twelve foot ceilings and private covered balcony bring a soothing airiness to this vaulted level
The daylight basement plan contains an optional two bedrooms, shared bathroom and multipurpose recreation room with patio access
The separate private entrance easily transforms this level into a home office or business space
Related Plan: For an alternate version with an unfinished lower level, see house plan 9819SW.
Plan Specifications
Area
Bedrooms & Bathrooms
Dimensions
Garage
Construction
Designer
What's Included in Your Plan Set
- Floor Plan with dimensions, window & door locations, ceiling heights
- Foundation Plan and ceiling joists layout
- Electrical Plan with outlet, switch and lighting locations
- Front, Rear & Side Elevations showing exterior finishes and roof pitches
- Wall Sections and Framing Details
- Door, Window and Roof Finish Schedules
Not sure? Contact us for advice
We can customise any plan to suit your stand size, lifestyle or local requirements.
Request a QuoteCalculate the cost to build and furnish your home in your area.
Request Report →All prices are in South African Rand (ZAR), excl. VAT. VAT at 15% is added at checkout. Prices subject to change without notice.
